Sabfoil Razor Blackbird Kit 2026

FREEWAVE & GLIDE
Razor Blackbird Kit
Choisissez votre combo entre les versions de tail, et mat=
7 combos Modular Backtail (tail démontable) et mat en 75 ou 85
ou
6 combos Integrated Backtail (tail fixe) et mat en 75 ou 85

==========================================================================

Les combos Modular Backtail (tail démontable) 7 combos, et mat en 75 ou 85
----------------------------------------------------------------------------------------------------
GR737-FCM-325-75 (ou 85)/BB: The Ultimate Surf & Carve Machine
Engineered for the critical sections of the wave, this full-carbon modular setup combines the razor-sharp speed of the 737 wing with a loose, flat stabilizer for explosive snaps and surgical carving. Experience granite-like stability in deep bottom turns and the total freedom to break the tail loose. Light, stiff, and hungry for high-speed rail-to-rail action.
Dimensions & Advanced specs
Front Wing - Span 737 mm
Front Wing - Surface 648 cm2
Front Wing - Aspect Ratio 8,4
Front Wing - Root Chord 108 mm
Front Wing - Maximum Thickness 14,7 mm
Stabilizer - Span 325 mm
Stabilizer - Surface 155 cm2
Stabilizer - Aspect Ratio 7,05
Stabilizer - Root Chord 58,9 mm
Stabilizer - Maximum Thickness 6,4 mm
Fuselage - Total Length 645 mm
Foil Set - Weight (ca.) kg
Mast - Height 750 mm
Mast - Board Connection Carbon Plate
----------------------------------------------------------------------------------------------------
Razor 847-SDW360-75 (ou 85) Blackbird Kit - Modular Full Carbon Backtail
High-aspect front wing with exceptional glide, unmatched pumpability, and top-tier performance for downwind and prone surf. Smooth, fast, and endlessly efficient.
Dimensions & Advanced specs
Front Wing - Span 847 mm
Front Wing - Surface 784 cm2
Front Wing - Aspect Ratio 9,20
Front Wing - Root Chord 115 mm
Front Wing - Maximum Thickness 16 mm
Stabilizer - Span 360 mm
Stabilizer - Surface 110 cm2
Stabilizer - Aspect Ratio 11,78
Stabilizer - Root Chord 44 mm
Stabilizer - Maximum Thickness 6,74 mm
Fuselage - Total Length 650 mm
Mast - Height 750 mm
Mast - Board Connection Carbon Plate
Foil Set - Weight (ca.) 3,61 kg
---------------------------------------------------------------------------------------------
Razor 977-SDW375-75( ou 85) Blackbird Kit - Modular Full Carbon Backtail
High-aspect front wing with exceptional glide, unmatched pumpability, and top-tier performance for downwind and prone surf. Smooth, fast, and endlessly efficient.
Dimensions & Advanced specs
Front Wing - Span 977 mm
Front Wing - Surface 953 cm2
Front Wing - Aspect Ratio 10,20
Front Wing - Root Chord 119 mm
Front Wing - Maximum Thickness 16,7 mm
Stabilizer - Span 375 mm
Stabilizer - Surface 130 cm2
Stabilizer - Aspect Ratio 10,40
Stabilizer - Root Chord 50 mm
Stabilizer - Maximum Thickness 7,7 mm
Fuselage - Total Length 655 mm
Mast - Height 750 mm
Mast - Board Connection Carbon Plate
Foil Set - Weight (ca.) 3,75 kg
----------------------------------------------------------------------------------------------
Razor 1077-SDW375-75 (ou 85) Blackbird Kit - Modular Full Carbon Backtail
High-aspect front wing with exceptional glide, unmatched pumpability, and top-tier performance for downwind and prone surf. Smooth, fast, and endlessly efficient.
Dimensions & Advanced specs
Front Wing - Span 1077 mm
Front Wing - Surface 1069 cm2
Front Wing - Aspect Ratio 11,00
Front Wing - Root Chord 124 mm
Front Wing - Maximum Thickness 17 mm
Stabilizer - Span 375 mm
Stabilizer - Surface 130 cm2
Stabilizer - Aspect Ratio 10,40
Stabilizer - Root Chord 50 mm
Stabilizer - Maximum Thickness 7,7 mm
Fuselage - Total Length 660 mm
Mast - Height 655 mm
Mast - Board Connection Carbon Plate
Foil Set - Weight (ca.) 3,85 kg
=============================================================================

Les combos Integrated Backtail (tail fixe) 6 combos, et mat en 75 ou 85 =
----------------------------------------------------------------------------------------------------
Blackbird Razor 847-345-75 (ou 85) hydrofoil complete set
Blackbird full carbon set high-aspect front wing with exceptional glide, unmatched pumpability, and top-tier performance for downwind and prone surf. Smooth, fast, and endlessly efficient.
Dimensions & Advanced specs
Front Wing - Span 847 mm
Front Wing - Surface 784 cm2
Front Wing - Aspect Ratio 9,2
Front Wing - Root Chord 115 mm
Front Wing - Maximum Thickness 16 mm
Stabilizer - Span 345 mm
Stabilizer - Surface 150 cm2
Stabilizer - Aspect Ratio 8,2
Stabilizer - Root Chord 64,4 mm
Stabilizer - Maximum Thickness 7,3 mm
Fuselage - Total Length 640 mm
Mast - Height 750 mm
Mast - Board Connection Carbon Plate
Foil Set - Weight (ca.) 3,5 kg
------------------------------------------------------------------------------------------------------------
Blackbird Razor 977-375-75 (ou 85) hydrofoil complete set
Blackbird full carbon set with exceptional glide, unmatched pumpability, and top-tier performance for downwind and prone surf. Smooth, fast, and endlessly efficient.
Dimensions & Advanced specs
Front Wing - Span 977 mm
Front Wing - Surface 953 cm2
Front Wing - Aspect Ratio 10,2
Front Wing - Root Chord 119 mm
Front Wing - Maximum Thickness 16,7 mm
Stabilizer - Span 375 mm
Stabilizer - Surface 130 cm2
Stabilizer - Aspect Ratio 10,4
Stabilizer - Root Chord 50 mm
Stabilizer - Maximum Thickness 7,7 mm
Fuselage - Total Length 650 mm
Mast - Height 750 mm
Mast - Board Connection Carbon Plate
Foil Set - Weight (ca.) 3,7 kg
--------------------------------------------------------------------------------------------
Razor 1077-SDW375-75 (ou 85) Blackbird Kit - Modular Full Carbon Backtail
High-aspect front wing with exceptional glide, unmatched pumpability, and top-tier performance for downwind and prone surf. Smooth, fast, and endlessly efficient.
Dimensions & Advanced specs
Front Wing - Span 1077 mm
Front Wing - Surface 1069 cm2
Front Wing - Aspect Ratio 11,00
Front Wing - Root Chord 124 mm
Front Wing - Maximum Thickness 17 mm
Stabilizer - Span 375 mm
Stabilizer - Surface 130 cm2
Stabilizer - Aspect Ratio 10,40
Stabilizer - Root Chord 50 mm
Stabilizer - Maximum Thickness 7,7 mm
Fuselage - Total Length 660 mm
Mast - Height 655 mm
Mast - Board Connection Carbon Plate
Foil Set - Weight (ca.) 3,85 kg

Aile avant	Aile arriere	Fuselage	Mat	Boitier
737	325	n.c	75	Platine 4 vis
847	360	n.c	75	Platine 4 vis
977	375	n.c	75	Platine 4 vis
1077	375	n.c	75	Platine 4 vis
737	325	n.c	85	Platine 4 vis
847	360	n.c	85	Platine 4 vis
977	375	n.c	85	Platine 4 vis
1077	375	n.c	85	Platine 4 vis
847	345	n.c	75	Platine 4 vis
977	375	n.c	75	Platine 4 vis
1077	375	n.c	75	Platine 4 vis
847	345	n.c	85	Platine 4 vis
977	375	n.c	85	Platine 4 vis
1077	375	n.c	85	Platine 4 vis
